American ESS Split Phase Inverter（battery voltage:48V）

American ESS Split Phase Inverter（battery voltage:48V）

● Higher yields, reduce electricity costs by 50% per year
● Free energy available at night
● Participate in peak load shifting to gain additional economic benefits
● keeping critical load operation in power off
● Support 7*24 remote service

American ESS Split Phase Inverter（battery voltage:48V）

● Solar Villa
● Telecom Base Station
● Solar Plus Storage
● Solar Farm
● Residential Rooftop
● Field Power Supply

American ESS Split Phase Inverter（battery voltage:48V）

SNE 120V/240V split phase 48V hybrid inverter is for North American market which is a high quality smart power solar inverter. This all in one inverter includes energy storage inverter and MPPT solar charge controller, working together with solar panels and 48V battery storage system, they make up a on grid off grid hybrid solar system, which can be widely used in various home storage application environments. It has multiple application modes such as self-consumption, peak shaving and valley filling, and backup power supply. Combined with smart display, it makes operation and maintenance easier. Our 8kw hybrid inverter is very popular in the market.

Category：SNE Energy Storage Inverter

SNE Energy Storage Inverter

Power Solar Inverter

All In One Inverter

Hybrid Solar Inverter

Message

Download

Product Features

Flexible configuration

Support multi-machine parallel connection, the maximum parallel connection can reach 8;

Support multi-machine parallel mode sharing a battery pack;

Single-machine load capacity 100A;

Safe and reliable

Battery reverse connection protection, anti-power control function;

Parallel available, intelligent BMS management;

Passed UL 1741:2021, IEEE 1547.1, UL1699B, South Africa NRS097-2-1:2017 test certification;

Convenient operation and maintenance

Support parallel SOC equalization control and parallel current sharing control;

Using split-phase topology and eliminating the transformers, to make the system efficiency higher;

Support the diesel generator and the grid access at the same time;

Advanced

Home smart energy management system;

Power dispatch and demand response management;

Equipped with CAN port, RS485 port, RS232 port for remote control, DRM port, which makes the system smart and flexible.

Benefits

● Solar Villa
● Telecom Base Station
● Solar Plus Storage
● Solar Farm
● Residential Rooftop
● Field Power Supply

Benefits

Application

● Solar Villa
● Telecom Base Station
● Solar Plus Storage
● Solar Farm
● Residential Rooftop
● Field Power Supply

Application

Model	SNE5K-DA	SNE6K-DA	SNE8K-DA	SNE10K-DA
PV input
Max. power(kW)	7.5kw	9kw	12kw	13kw
MPPT voltage range(V)	120 - 500V
Max. DC voltage (V)	500V
Max.Input current of single MPPT(A)	12A
MPPT tracker/strings	4/2
AC output
Rated output power(kVA)	5KVA	6KVA	8KVA	10KVA
Max. output current(A)	24A	28.8A	38.3A	47.8A
Ac output voltage(V)	120/240(split phase), 208(2/3 phase),230 (single phase)
Frequency (Hz)	50/60Hz
Power factor	0.8leading…0.8lagging
THDI	< 3%
AC output topology	Split phase, 2/3 phase, single phase
Battery
Battery voltage range(V)	40V~58V
Max. charging voltage(V)	58V
Max. charge/discharge current(A)	120A/120A	135A/135A	190A/190A	210A/210A
Battery type	Lithium/Lead-acid
Communication	CAN,RS485
EPS output
Rated power(kVA)	5KVA	6KVA	8KVA	10KVA
Rated output voltage(V)	120/240 (split phase), 208 (2/3 phase),230 (single phase)
Rated output current(A)	24A	28.8A	38.3A	47.8A
Rated frequency(Hz)	50/60Hz
Automatic switching time(ms)	＜20ms
Output THDu	< 2%
Overload capacity	125%,60S/150%,1S
General data
Max efficiency	≥98.2%
North american efficiency	≥97.2%
Ingress protection	IP65/NEMA 3R
Noise emission(dB)	<25dB	<29dB	<29dB	<29dB
Cooling	Natural
Operation temperature	.-25℃ ~ 60℃
Relative humidity	0-95%（non-condensing）
Altitude	2,000m(>2,000 Derating)
Weight(kg)	41kg
Dimensions W D H (mm)	430220710MM
Isolation transformer	No
Self-consumption(W)	<3w
Display and communication
Display	LCD, touch screen
Interface:RS485/Wifi/4G/ CAN/DRM	Yes
Safety standard	UL1741SA all options, UL1699B, CSA 22.2
EMC	FCC Part 15, Class B
On-grid	IEEE 1547, IEEE 2030.5, Hawaii Rule 14H, Rule 21 Phase I,II,III,NRS
